BotWing F722 Mini Flight Controller

BotWing F722 Mini Flight Controller

₹ 5,299
₹ 8,399 ₹ 5,299
Sale Sold out
Shipping calculated at checkout.

BotWing F7 Guide- mini

Firmware_betaflight

Firmware_inav

    Powerful F7 Mini Flight Controller: Built with STM32F722RET6 chip and ICM42688P IMU for smooth, accurate flight control.
    Flexible Software Support; Multiple Outputs: Compatible with Betaflight/iNav, offering 4 motor and 2 servo outputs for diverse applications.
    Standard Build Size: 30 × 30 mm board with 20 × 20 mm mounting holes for easy integration.
    Reliable Power & Logging: Supports 3-6S LiPo batteries, onboard OSD, and Blackbox for logging and performance tracking.
    Beginner-Friendly Connectivity: Simple connections for ESCs, GPS, ELRS/SBUS receivers, VTX, and LED strips, with clear diagrams for soldered and plug-in installations.

    The F722 Mini Flight Controller is a high-performance F7 flight controller designed for precision, flexibility, and reliable performance in every drone build.

    • 1-Year Warranty
    • Free Delivery above 1499
    • Proudly Made in India
    • Delhi-NCR Same day Delivery
    • Cash on Delivery Available
    • Pan-India Shipping
    View full details

    FAQs

    1. Does the F722 Mini use the same processor as a full-size F722 board?

    Yes. The F722 Mini uses the same 32-bit STM32F722 processor found on standard full-size F722 flight controllers.

    2. Is there any performance difference compared to a full-size F722 board?

    No. Processing performance is the same. Flight behaviour depends on tuning and firmware, not board size.

    3. How many UART ports does the F722 MINI support?

    The F722 MINI supports 5 UART ports for connecting multiple peripherals.

    4. Can GPS, ELRS, and FPV systems be used at the same time?

    Yes. The available UARTs allow simultaneous use of GPS, radio receiver, FPV system, telemetry, and additional modules.

    5. Does the F722 MINI support servo outputs?

    Yes. The board supports 2 dedicated servo outputs, suitable for pan-tilt systems, control surfaces, or custom UAV setups.

    6. What is the mounting size of the F722 MINI?

    It uses a 20 × 20 mm hole-to-hole mounting pattern, designed for compact and modern FPV frames.

    7. How does its size compare to a standard full-size F722 board?

    Standard F722 boards use a 30.5 × 30.5 mm mounting pattern, making the F722 MINI 57% smaller in footprint.

    8. What is the difference between hole-to-hole and edge-to-edge size?

    Hole-to-hole refers to mounting spacing, while edge-to-edge is the physical PCB size. The F722 MINI is smaller in both dimensions, allowing lighter and cleaner builds.

    9. Does the F722 MINI include onboard memory?

    Yes. It includes 16 MB of onboard flash memory for black box logging and flight analysis.

    10. What is the operating temperature range of the F722 MINI?

    The controller is rated for operation between −15°C and +85°C, suitable for varied flying environments.

    11. Does the F722 MINI support FPV systems, including DJI O3?

    Yes. The F722 MINI supports FPV systems, including DJI O3.
